AIR CASTERS

Air Film Technology

Air Casters for Heavy Load Handling on a bearing of air. The latest on Air Film Technology in the Material Handling Industry. Replacement Air Casters, Rentals, rigging equipment and Air Film Systems. Also Wheeled vehicles with omni-directional steering for handling heavy loads.



"Float Heavy

Loads on Air"

AUTOMATED GUIDED VEHICLES

AUTOMATED MATERIAL HANDLING SYSTEM FOR HEAVY LOAD HANDLING

Air Bearings have increased the capacity of Automated Guided Vehicles (AGV's) and SOLVING is a world leader when it comes to automated material handling systems for the heavy Load handling.



Automated Material Handling System for handling ship components in welding area



Automated Guided Vehicles for handling Large Paper Mill Rolls automatically.

Automated Material Handling 'Air Film Transporter' moves prefabricated components up to 50 Tons between welding robot stations.



SOLVING's Automated Guided Air Film Transporter vehicle for delivering up to 80 Ton Mill Rolls for the Paper Industry.



Automatically guided Paper Roll material handling system on air casters

automated guided vehicle system for handling Rolls and reels automatically



GUIDANCE

FOR AUTOMATED MATERIAL HANDLING SYSTEMS

Different guidance methods can be chosen depending on varying factors such as the customer’s requirements, frequency of transportation, existing facilities, cost of installation and future expansion. A combination of automated guidance systems is also possible.



The three most common automatic navigational systems are laser, wire and tape guidance described below.



Laser guidance:

The laser technique provides the customer with extensive freedom because the automated guided vehicle system does not need any tracks, wires or rails, but can be easily programmed for both indoor and outdoor driving. The driving routes can easily be changed within the software. This up-to-date technology uses the optical triangulation principle; a rotating laser beam detects reflectors that are placed in the building, and based on these locations the hardware installed in the AGV continuously calculates its navigational route in real time. Information is transferred via radio.


Wire guidance:

Wire guidance is a well-proven navigation system where the automated vehicle follows a wire laid in the floor. Information is transferred via the wire, radio or defined information points to a host computer. Wire guidance can be applied to both indoor and outdoor use.


Tape guidance:

The automated vehicle follows a taped or painted line on the floor via a camera. Information is transferred via radio communication. Tape guidance is only suitable for indoor use.



AUTOMATED MATERIAL HANDLING SYSTEMS & APPLICATIONS

automatically positioned Turntable materail handling system



Automated material handling system, automatically handles heavy loads



automatic indexing turntable, Turn Tables that automatically position heavy loads for material handling systems



Automated guided vehicle systems for handling heavy loads in the steel and stamping industry

16' Dia.  / 10,000 lbs capacity, This Precision Turntable is able to be programmed to rotate and stop anywhere on it's 360 degree axis within +/- 1/2 degree of accuracy.



These Iron Powder containers, which weigh up to 10 tons, are transported during production on Air Film based Laser Navigated Automated Guided Vehicles.

  64' Dia. / 1200 tons. Synchronized Drive Units, Control the speed of rotation on these three large automated Turntables, adjusting to suit production of subsea umbilicals.    Air Film Transporter used for automatically transporting steel coils between crane bays. Loaded & unloaded by Overhead Crane, with Crane Operator  transmitting the signal.













More Solving AGV Systems coming soon ...
